Plate from Astrograph, Bamberg Northern Sky Patrol
| Applause ID: | dr.4/plates/208_88193 |
| Archive: | Astrograph, Bamberg Northern Sky Patrol |
| Plate number in archive: | 011260 |
| Institute: | Dr. Karl Remeis-Sternwarte, Bamberg |
| Observer name: | H.-U. Sandig |
| Observer notes: | lim.mag=14 |
| Miscellaneous notes: | |
| Bibcode of related paper: | |
| Plate series: | |
| Dispersion: | |
| Plate development information: | |
| Plate quality: | |
| Plate notes: | stray light all edges |
| Plate format: | 9x12 cm |
| Emulsion: | Perutz Spektral Rot |
| Original recorded date: | 1948-09-09 |
| Number of exposures: | 1 |
| Observatory name: | Dr. Remeis-Observatory |
| Observatory site name: | Dr. Remeis-Observatory, Bamberg, Germany |
| East longitude of the observing site: | 49.8845 deg |
| Latitude of the observing site: | 10.8881 deg |
| Elevation of the observatory site: | 288.0 m |
| Clear aperture of the telescope: | |
| Focal length of the telescope: | 0.5 m |
| Plate scale of the telescope: | 417.0 arcsec/mm |
| Instrument name: | |
| Observation filter: | |
| Observation method code (following WFPDB): | |
| Observation prism used: | |
| Used grating: | |
| Air temperature: | |
| Calmness (seeing conditions): | |
| Sharpness: | |
| Transparency: | very good |
| Notes on sky conditions: | very good transparency |
| Filename scan: | 011260_1948_h.fits |
| Length of data axis 1: | 8092 |
| Length of data axis 2: | 10760 |
| Min. value in the image: | 409 |
| Max. value in the image: | 65532 |
| Scanner name: | Epson Expression 10000XL |
| Scanner software: | VueScan 9 X64 (9.5.50) Professional Edition |
| Scanner gamma value: | 1.0 |
| Scanner focus: | -0.375 |
| Resolution of axis 1: | 2400 dpi |
| Resolution of axis 2: | 2400 dpi |
| Pixel size along axis 1: | 10.5833 um |
| Pixel size along axis 2: | 10.5833 um |
| Scan date and time: | |
| Author of the scan: | H. Edelmann |
| Notes about the scan: | scan orientation: 14 |
| Institute responsible for the scan: | Dr. Karl Remeis-Sternwarte, Bamberg |
Digital object identifier
You can use the following DOI to cite this photographic plate in a publication:
License
This photographic plate is published under the CC0 1.0 Universal (CC0 1.0).
