Plate from Bamberg Southern Sky Patrol (Argentina)
Preview
Envelope
(link)
| Applause ID: | dr.3/plates/205_45615 |
| Archive: | Bamberg Southern Sky Patrol (Argentina) |
| Plate number in archive: | 303 |
| Institute: | Dr. Karl Remeis-Sternwarte, Bamberg |
| Observer name: | Alarcon |
| Observer notes: | |
| Miscellaneous notes: | on envelope: JD is not matching to observing time |
| Bibcode of related paper: | |
| Plate series: | Bamberg Southern Sky Patrol |
| Dispersion: | |
| Plate development information: | |
| Plate quality: | 2 |
| Plate notes: | dark, emulsion problem, weak halo, few tiny emulsion defects |
| Plate format: | 16x16 cm |
| Emulsion: | Gevaert 67A50 |
| Original recorded date: | 1971-04-19 |
| Number of exposures: | 1 |
| Observatory name: | Dr. Remeis-Observatory; Southern Station |
| Observatory site name: | Observatorio de Fisica Cosmica; San Miguel; Argentina |
| East longitude of the observing site: | -34.5567 deg |
| Latitude of the observing site: | -58.7317 deg |
| Elevation of the observatory site: | 37.0 m |
| Clear aperture of the telescope: | 0.1 m |
| Focal length of the telescope: | 0.61 m |
| Plate scale of the telescope: | 338.0 arcsec/mm |
| Instrument name: | |
| Observation filter: | NONE |
| Observation method code (following WFPDB): | |
| Observation prism used: | |
| Used grating: | |
| Air temperature: | |
| Calmness (seeing conditions): | |
| Sharpness: | |
| Transparency: | |
| Notes on sky conditions: |
| Filename scan: | 000303_1971_h.fits |
| Header file (DR3): | 000303_1971_h.hdr |
| Length of data axis 1: | 14001 |
| Length of data axis 2: | 14381 |
| Min. value in the image: | 484 |
| Max. value in the image: | 65532 |
| Scanner name: | Epson Expression 10000XL |
| Scanner software: | VueScan 9 X64 (9.5.50) Professional Edition |
| Scanner gamma value: | 1.0 |
| Scanner focus: | -0.425 |
| Resolution of axis 1: | 2400 dpi |
| Resolution of axis 2: | 2400 dpi |
| Pixel size along axis 1: | 10.5833 um |
| Pixel size along axis 2: | 10.5833 um |
| Scan date and time: | Aug. 26, 2016, 5:16 p.m. |
| Author of the scan: | H. Edelmann |
| Notes about the scan: | scan orientation: 14 |
| Institute responsible for the scan: | Dr. Karl Remeis-Sternwarte, Bamberg |
Digital object identifier
You can use the following DOI to cite this photographic plate in a publication:
License
This photographic plate is published under the CC0 1.0 Universal (CC0 1.0).
